Brawa 99801 Sound Decoder SD22A-4

Brawa 99801 Sound Decoder SD22A-4

  • £86.50




HO Scale

Sound decoder SD22A-4

For PluX22 interface, 22-pin



Operating modes DCC SX1, SX2, MM, DC analogue

Dimensions [mm] 30.2 x 15.8 x 5.2

Overall capacity 2.0 A

Max. engine current 2.0 A

Max. running voltage 30 V

2 light outputs, dimmable to 150 mA each

2 additional outputs, dimmable to 300 mA each

2 additional outputs, 1.0 A each

With SUSI interface

Sampling rate 22 kHz

8 independent sound channels

32-megabit memory

Storage duration up to 190 s

Max. output power 1.4 W (4 Ohm)

PluX22 Adaptor to cable (order no. 99813)

99801
